BMW 5 series E60/E61 (2002-2007) txd sig wiring diagram
This page shows the only wiring diagram for the component.txd sig, which is found in the car BMW 5 series E60/E61 (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
txd sig wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRAKES SOLENOID VALVE
BRK SOL V SUPPLY SHIFT SENS HYD PRESS
BRN WIRE
BRN/BLK WIRE
CAN-H- CAN-L-
CAN-L CAN-H
CLUTCH POS RETURN GROUND
CLUTCH POS SELECT ANGLE CLUTCH POS
CLUTCH POSITION SENSOR
CLUTCH SOLENOID VALVE
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS (DME) CONTROL UNIT (RIGHT REAR OF ENGINE COMPT)
E BOX (RIGHT REAR OF ENGINE COMPT)
FUSE
GEAR 1 SOL CLUTCH SOL
GEAR 1 SOLENOID VALVE
GEAR 2 SOL IGNITION
GEAR 2 SOLENOID VALVE
GEARSHIFT SENSOR
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HYDRAULIC PRESSURE SENSOR
HYDRAULIC PUMP
HYDRAULIC PUMP RELAY
NCA WIRE
PUMP RELAY
RED WIRE
RED/WHT WIRE
RPM SENS RPM SENS
RPM SENSOR
SELECTOR ANGLE SENSOR
SEQUENTIAL MANUAL TRANSMISSION (SMG)
TXD
TXD SIG
VIO WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> 6-speed smg circuit (2 of 2) -> TXD SIG
