BMW 5 series E60/E61 (2002-2007) data link Wiring diagrams
This page contains all the electrical diagrams for the component. data link, in which he is found in the car BMW 5 series E60/E61 (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram data link (1 of 2)
ANTI-THEFT SYSTEM
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRAKE LT SIG
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
COOLING FANS SYSTEM ANTI-LOCK BRAKES SYSTEM
COOLING FANS SYSTEM ANTI-THEFT SYSTEM
DATA LINK
ENGINE CONTROL MODULE (LEFT REAR ENGINE COMPT)
GROUND GROUND IGN COIL 6 SIG IGN COIL 5 SIG IGN COIL 4 SIG
IGN COIL 3 SIG (TER 2-3 NOT USED)
IGNITION COILS
LEAK DIAG (+)
LEAK DIAG (+) AIR PMP SIG ELECTRIC FAN AIR MASS METER (-)
NCA WIRE
ORG/ WIRE
PLUG
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
SECONDARY AIR HOT-FILM AIR MASS METER
SECONDARY AIR INJECTION PUMP
SECONDARY AIR INJECTION PUMP RELAY
SENSOR GROUND SENSOR GROUND SENSOR GROUND SENSOR GROUND SENSOR GROUND
SENSOR GROUND SENSOR SIGNAL SENSOR (+) AIR MASS METER SIG
SENSOR GROUND SENSOR SIGNAL SENSOR (+) FUEL PUMP (+)
SENSOR GROUND SENSOR SIGNAL SENSOR SIGNAL SENSOR SIGNAL SENSOR SIGNAL
SENSOR SIGNAL SENSOR SIGNAL SENSOR SIGNAL SENSOR SIGNAL TERM 87
WAKE-UP
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 2.5l (4 of 4) -> DATA LINK
Wiring diagram data link (2 of 2)
ANTI-THEFT SYSTEM
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRAKE LT SIG
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
COOLING FANS SYSTEM ANTI-LOCK BRAKES SYSTEM
COOLING FANS SYSTEM ANTI-THEFT SYSTEM
DATA LINK
ENGINE CONTROL MODULE (LEFT REAR ENGINE COMPT)
GROUND GROUND IGN COIL 6 SIG IGN COIL 5 SIG IGN COIL 4 SIG
IGN COIL 3 SIG (TER 2-3 NOT USED)
IGNITION COILS
LEAK DIAG (+)
LEAK DIAG (+) AIR PMP SIG ELECTRIC FAN AIR MASS METER (-)
NCA WIRE
ORG/ WIRE
PLUG
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
SECONDARY AIR HOT-FILM AIR MASS METER
SECONDARY AIR INJECTION PUMP
SECONDARY AIR INJECTION PUMP RELAY
SENSOR GROUND SENSOR GROUND SENSOR GROUND SENSOR GROUND SENSOR GROUND
SENSOR GROUND SENSOR SIGNAL SENSOR (+) AIR MASS METER SIG
SENSOR GROUND SENSOR SIGNAL SENSOR (+) FUEL PUMP (+)
SENSOR GROUND SENSOR SIGNAL SENSOR SIGNAL SENSOR SIGNAL SENSOR SIGNAL
SENSOR SIGNAL SENSOR SIGNAL SENSOR SIGNAL SENSOR SIGNAL TERM 87
WAKE-UP
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 3.0l (4 of 4) -> DATA LINK
