Trunk & fuel door release circuit for BMW 5 series E39 facelift (2000-2004)
Trunk & fuel door release circuit
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CENTRAL LOCKING FUEL TANK ACCESS FLAP RELAY
DOOR LOCKS SYSTEM
FUEL TANK ACCESS FLAP LOCK MOTOR
FUSE PANEL 2
GENERAL MODULE (BEHIND GLOVE BOX)
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES FUSE
HOT AT ALL TIMES FUSE PANEL 1 FUSE
REAR LID MOTOR RELAY
RED/BLK WIRE
RED/GRY WIRE
SEDAN
SEDAN WAGON
TRUNK LID RELEASE SWITCH
WAGON
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
ZV DRIVE REAR LID
