Power windows circuit for BMW 5 series E39 facelift (2000-2004)
Power windows circuit (1 of 2)
AUTO CLOSE
AUTO OPEN
BLK/GRN WIRE
BLK/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
CLOSE
DRIVER'S DOOR MODULE
DRIVER'S SIDE PRESSURE, SENSITIVE FINGER GUARD
DRIVER'S WINDOW MOTOR
FUSE PANEL 1
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES FUSE
OFF
PASSENGER'S DOOR MODULE
PASSENGER'S POWER WINDOW SWITCH
PASSENGER'S SIDE PRESSURE- SENSITIVE FINGER GUARD
PASSENGER'S WINDOW MOTOR
RED/VIO WIRE
RED/WHT WIRE
RED/WHT/YEL WIRE
SUNROOF MODULE
TO GENERAL MODULE (DIAGRAM 2 OF 2)
YEL WIRE
Power windows circuit (2 of 2)
AUTO CLOSE
AUTO OPEN
BLK/BRN WIRE
BLK/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CLOSE
FROM DRIVER'S MODULE (DIAGRAM 1 OF 2)
FUSE PANEL 1
GENERAL MODULE (BEHIND GLOVE COMPARTMENT)
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES FUSE
LEFT REAR POWER WINDOW SWITCH
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW PRESSURE SENSITIVE FINGER GUARD
OFF
OFF CLOSE
OFF OPEN
OPEN AUTO
RED WIRE
RED/GRY WIRE
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW PRESSURE- SENSITIVE FINGER GUARD
