Power door locks circuit for BMW 5 series E39 facelift (2000-2004)
Power door locks circuit (1 of 2)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
CENTRAL LOCKING FUEL TANK ACCESS FLAP RELAY
DRIVER'S DOOR LOCK SWITCH
DRIVER'S DOOR MODULE
FUSE
FUSE PANEL 1
FUSE PANEL 2
GENERAL MODULE (BEHIND GLOVE COMPARTMENT)
GLOBAL LOCKING SWITCH
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
NCA WIRE
PASSENGER'S DOOR MODULE
REAR WINDOW SERVO OPENING SWITCH
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT/YEL WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
TRUNK LID LOCKING SWITCH (W/O REAR LID MODULE)
TRUNK LID SERVO MOTOR (WAGON)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Power door locks circuit (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVERS DOOR LOCK MOTOR
FUSE
FUSE PANEL 2
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSIDE REAR LID PUSH BUTTON
LEFT REAR DOOR LOCK MOTOR
LIFT GATE LOCK SWITCH
NCA WIRE
PASSENGERS DOOR LOCK MOTOR
REAR LID HYDRAULIC PUMP
REAR LID MODULE
REAR LID TILT SWITCH
REAR WINDOW SERVO MOTOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT REAR DOOR LOCK MOTOR
TRUNK LID LOCKING SWITCH (W/ REAR LID MODULE)
WHT WIRE
WHT/BLU WIRE
WHT/RED/YEL WIRE
WHT/YEL WIRE
WINDOW MOTOR RELAY
YEL WIRE
