Trailer tow circuit, sedan for BMW 5 series E39 facelift (2000-2004)
Trailer tow circuit, sedan
BLK/BLU WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/BRN/YEL WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE LIGHT
BRN WIRE
FUSE
FUSE PANEL 2
FUSE PANEL 5
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT REAR LIGHT ASSEMBLY 1
LIGHT CONTROL MODULE (RIGHT KICK PANEL)
RED WIRE
RED/BLU WIRE
RIGHT REAR LIGHT ASSEMBLY 1
TAIL- LIGHT
TRAILER CONNECTOR
TRAILER MODULE (AHM)
TURN LIGHT
WHT/BRN WIRE
YEL/BLU WIRE
YEL/RED WIRE
