Backup lamps circuit, sedan for BMW 5 series E39 facelift (2000-2004)
Backup lamps circuit, sedan
2.5L, 2.8L 3.0L
2.5L, 3.0L
3 3 (1999, 2000) (2001, 2002, 2003)
BACK- UP LIGHT
BACK-UP LIGHT SWITCH
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (DME)
FUSE
FUSE PANEL 1
GRN WIRE
GRY WIRE
GRY/VIO WIRE
HOT ACC, RUN OR START
LEFT REAR LIGHT ASSEMBLY 1
LIGHT CONTROL MODULE (RIGHT KICK PANEL)
M/T 2.8L, 4.4L
RED WIRE
RIGHT REAR LIGHT ASSEMBLY 1
VIO WIRE
W/ IKE W/O IKE
WHT WIRE
WHT/GRY WIRE
WHT/GRY/YEL WIRE
WHT/YEL WIRE
YEL WIRE
