BMW 5 series E39 facelift (2000-2004) voice transceiver/ box charging electronics Wiring diagram
This page shows the only wiring diagram for the component.voice transceiver/ box charging electronics, which is found in the car BMW 5 series E39 facelift (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram voice transceiver/ box charging electronics (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
BRN/ORG WIRE
COIL SPRING
COMPUTER DATA LINES SYSTEM
DIVERSITY
ENGINE CONTROL MODULE (DME)
FM AMPLIFIER LOCKOUT CIRCUIT
FUSE FUSE
FUSE PANEL 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES FUSE PANEL 2 FUSE
HOT IN ACC, RUN OR START
LEFT TV AMPLIFIER
NCA WIRE
REAR WINDOW
RED WIRE
RED/GRN WIRE
UNLOADER RELAY TERMINAL R (RIGHT REAR OF LUGGAGE COMPT)
VIO WIRE
VIO/RED WIRE
VIO/WHT WIRE
VOICE TRANSCEIVER/ BOX CHARGING ELECTRONICS
W/ ONBOARD MONITOR
W/O ONBOARD MONITOR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Premium radio circuit, sedan with hifi radio (2 of 3) -> VOICE TRANSCEIVER/ BOX CHARGING ELECTRONICS
