BMW 5 series E39 facelift (2000-2004) off open Wiring diagram
This page shows the only wiring diagram for the component.off open, which is found in the car BMW 5 series E39 facelift (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off open (1 of 1)
AUTO CLOSE
AUTO OPEN
BLK/BRN WIRE
BLK/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CLOSE
FROM DRIVER'S MODULE (DIAGRAM 1 OF 2)
FUSE PANEL 1
GENERAL MODULE (BEHIND GLOVE COMPARTMENT)
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES FUSE
LEFT REAR POWER WINDOW SWITCH
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW PRESSURE SENSITIVE FINGER GUARD
OFF
OFF CLOSE
OFF OPEN
OPEN AUTO
RED WIRE
RED/GRY WIRE
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW PRESSURE- SENSITIVE FINGER GUARD
Go to component -> Power windows circuit (2 of 2) -> OFF OPEN
