BMW 5 series E39 facelift (2000-2004) electronic shock absorber control module Wiring diagram
This page shows the only wiring diagram for the component.electronic shock absorber control module, which is found in the car BMW 5 series E39 facelift (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic shock absorber control module (1 of 1)
2.5L, 3.0L
4 3 CAN H CAN L
4.4L A/T
40 24 11 CAN L CAN H
A/T
ABS/ASC OR ABS/DSC CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
AGS TRANSMISSION CONTROL MODULE
BLK WIRE
BRN WIRE
BRN/BLK WIRE
CAN-L CAN-H
ELECTRONIC SHOCK ABSORBER CONTROL MODULE
ENGINE CONTROL MODULE (DME) (LEFT REAR OF ENGINE COMPT)
FUSE PANEL 1
GRN/WHT WIRE
HOT AT ALL TIMES FUSE
HOT IN RUN OR START FUSE
OBDII PLUG (CENTER CONSOLE)
RED/BLK WIRE
STEERING ANGLE SENSOR (W/ ABS/DSC)
TRANSMISSION W/ 8.34, 8.70 TRANSMISSION
W/ ABS/DSC
W/ IKE W/O IKE
WHT/VIO WIRE
WHT/VIO/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Data link connector circuit -> ELECTRONIC SHOCK ABSORBER CONTROL MODULE
