Headlamps leveling circuit for BMW 5 series E39 (1995-2000)
Headlamps leveling circuit
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE PANEL 1 FUSE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HEADLIGHT WIDENING CONTROL MODULE (BEHIND GLOVE COMPARTMENT)
HOT IN ACC, RUN OR START
LEFT ACTUATOR FOR HEADLIGHT BEAM THROW CONTROL
LIGHT MODULE
RED WIRE
RIGHT ACTUATOR FOR HEADLIGHT BEAM THROW CONTROL
RIGHT FRONT LEVEL SENSOR
RIGHT REAR LEVEL SENSOR
VIO/YEL WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
