BMW 5 series E39 (1995-2000) left rear valve Wiring diagram
This page shows the only wiring diagram for the component.left rear valve, which is found in the car BMW 5 series E39 (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear valve (1 of 1)
AIR SUSPENSION CONTROL UNIT (RIGHT SIDE OF LUGGAGE COMPT)
BLU/BLK WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
COMPRESSOR PUMP CONTROL RELAY
COMPUTER DATA LINES STYSTEM
DOWN VALVE
FUSE 50
FUSE PANEL 2
HOT AT ALL TIMES
LEFT REAR LEVEL SENSOR
LEFT REAR VALVE
RED WIRE
RED/BRN WIRE
RED/YEL WIRE
RIGHT REAR RIDE-LEVEL SENSOR
RIGHT REAR VALVE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED/YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Electronic air suspension circuit -> LEFT REAR VALVE
