BMW 5 series E39 (1995-2000) electronic shock absorber control module Wiring diagram
This page shows the only wiring diagram for the component.electronic shock absorber control module, which is found in the car BMW 5 series E39 (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic shock absorber control module (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CRUISE CONTROL MODULE (LEFT SIDE OF DRIVER'S FOOTWELL)
ELECTRONIC SHOCK ABSORBER CONTROL MODULE
ENGINE CONTROL MODULE (REAR RIGHT SIDE OF ENG COMPT, IN E-BOX)
FUSE
FUSE BLOCK (IN GLOVE BOX TOP)
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ACCY, RUN, OR START
HOT IN RUN OR START
INSTRUMENT CLUSTER
INTEGRATED INSTURMENT CLUSTER CONTROL MODULE (BEHIND INSTRUMENT CLUSTER)
OBDII PLUG (CENTER CONSOLE)
RED WIRE
RED/BLK WIRE
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL MODULE
TRANSMISSION CONTROL MODULE (REAR RIGHT SIDE OF ENG COMPT, IN E-BOX)
VIO/WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WHT/VIO/YEL WIRE
WHT/YEL WIRE
Go to component -> Computer data lines circuit -> ELECTRONIC SHOCK ABSORBER CONTROL MODULE
