Electrical box fan circuit for BMW 5 series E34 (1988-1996)
Electrical box fan circuit
1995 VFTC
BATTERY
BRN (OR BRN/ORG) WIRE
BRN WIRE
E-BOX FAN (REAR RIGHT SIDE OF ENGINE COMPARTMENT)
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT)
FUEL PUMP RELAY (IN E-BOX)
GRN WIRE
GRN/VIO WIRE
HOT IN START AND RUN FUSE
INSTRUMENT CLUSTER OIL WARNING IND
NCA WIRE
OIL PRESSURE SWITCH (FRONT OF ENGINE ON COOLANT INLET)
RED WIRE
TEMPERATURE SWITCH (TOP REAR OF ENGINE ON COOLANT INLET)
