Auxiliary cooling fan circuit for BMW 5 series E34 (1988-1996)
Auxiliary cooling fan circuit
AUXILIARY FAN MOTOR
BLK/BLU WIRE
BLK/GRY WIRE
BLK/GRY/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPRESSOR CONTROL
ENGINE CONTROL MODULE (IN E-BOX)
FRONT POWER DISTRI- BUTION BOX
FUSE 25
FUSE 29
GRN/BLU/YEL WIRE
HIGH SPEED RELAY (IN LEFT AUXILIARY RELAY BOX)
HOT AT ALL TIMES
HOT IN RUN OR START
INTEGRATED CLIMATE REGULATION CONTROL MODULE (ABOVE CENTER CONSOLE)
NORMAL SPEED RELAY (IN POWER DISTRIBUTION BOX)
PRESSURE SWITCH (REAR RIGHT HEADLIGHT)
RED/GRN WIRE
TEMPER- ATURE SWITCH (RIGHT TOP OF RADIATOR)
VIO/GRN WIRE
