BMW 5 series E34 (1988-1996) sig line Wiring diagram

ABS HYDRAULIC UNIT (LEFT SIDE OF ENGINE COMPARTMENT) ABS IND. ASC IND ASC SWITCH AUXILIARY THROTTLE MOTOR (NEAR THROTTLE BODY) AUXILIARY THROTTLE POSITION SENSOR (TOP FRONT OF ENGINE COMPARTMENT) BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO/YEL WIRE BLU WIRE BLU/RED WIRE BLU/VIO/YEL WIRE BRAKE LIGHT SWITCH (ON BRAKE PEDAL) BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN/YEL WIRE BRN/GRY WIRE BRN/ORG OR BLK/GRN WIRE BRN/RED WIRE CARBON CANISTER (BEHIND LEFT FRONT FOG LIGHT) DATA LINK CONNECTOR (NEAR E-BOX, LEFT) ENGINE CONTROL MODULE (DME) (IN E-BOX) FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT) FUSE GRN WIRE GRN/BLU/YEL WIRE GRN/RED WIRE GROUND GRY/BLK WIRE GRY/BLK/YEL WIRE GRY/RED WIRE HOT IN ACCY, RUN, OR START HOT IN RUN AND START INSTRUMENT CLUSTER INTAKE VALVE LEFT FOOTWELL) LEFT FRONT INLET VALVE LEFT FRONT OUTLET VALVE LEFT REAR INLET VALVE LEFT REAR OUTLET VALVE NCA WIRE PARK BRAKE SIG IGN TIMING SIG PARK BRAKE SWITCH (BELOW CENTER OF CONSOLE) PLUNGER VALVE PUMP MOTOR RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT INLET VALVE RIGHT FRONT OUTLET VALVE RIGHT REAR INLET VALVE RIGHT REAR OUTLET VALVE SIG LINE SLIP CONTROL MODULE (ABS/ASC) (REAR RIGHT SIDE OF ENGINE COMPARTMENT) THROT ANGLE SIG THROTTLE POSITION SENSOR (TOP FRONT OF ENGINE COMPARTMENT) TRANS INTERVENTION VIO WIRE WHT/BLK OR YEL/VIO WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/VIO WIRE YEL/WHT WIRE
