BMW 5 series E34 (1988-1996) on-board computer cruise control module Wiring diagram
This page shows the only wiring diagram for the component.on-board computer cruise control module, which is found in the car BMW 5 series E34 (1988-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on-board computer cruise control module (1 of 1)
ANTI- THEFT CONTROL MODULE
AUXILIARY FAN MOTOR
AUXILIARY WATER PUMP
BRAKE FLUID LEVEL SWITCH
BRN WIRE
BRN/ORG WIRE
CRUISE CONTROL ACTUATOR
FUEL LEVEL SENSOR
HEADLIGHT/ FOGLIGHT CLEANING MODULE (SRA)
INSTRUMENT CLUSTER
LAMP CONTROL MODULE CHECK CONTROL MODULE
LEFT FOG LIGHT
LEFT FRONT LIGHT ASSEMBLY
LEFT FRONT MARKER LIGHT
LEFT FRONT TURN LIGHT
LEFT HIGH BEAM LIGHT
LEFT HORN
LEFT LOW BEAM LIGHT
LEFT PARK LIGHT
LEFT REAR LIGHT ASSEMBLY LEFT BRAKE LIGHT LEFT TAIL LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN LIGHT
NCA WIRE
ON-BOARD COMPUTER CRUISE CONTROL MODULE
PRESSURE SENSOR/ PLUNGER
RIGHT BRAKE LIGHT RIGHT REAR TURN LIGHT
RIGHT FOG LIGHT
RIGHT FRONT DOOR JAMB SWITCH REAR WIPER/ WASHER FLUID LEVEL SWITCH
RIGHT FRONT LIGHT ASSEMBLY
RIGHT FRONT MARKER LIGHT
RIGHT FRONT SEAT BELT SWITCH (LATE PRODUCTION)
RIGHT FRONT TURN LIGHT
RIGHT FRONT WINDOW LIMIT SWITCH RIGHT REAR QUARTER WINDOW SWITCH (DMA)
RIGHT FRONT WINDOW MONITORING SWITCH (DWA)
RIGHT HIGH BEAM LIGHT
RIGHT HORN
RIGHT LOW BEAM LIGHT
RIGHT PARK LIGHT
RIGHT REAR DOOR JAMB SWITCH
RIGHT REAR LIGHT ASSEMBLY RIGHT TAIL LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR WINDOW LIMIT SWITCH
SLIP CONTROL MODULE (ABS/ASC)
STARTER IMMOBILIZATION RELAY (LATE PRODUCTION)
TELEPHONE INTERFACE
TELEPHONE TRANSCEIVER
THROTTLE FLAP HEATER
Go to component -> Ground distribution circuit (5 of 6) -> ON-BOARD COMPUTER CRUISE CONTROL MODULE
