BMW 5 series E34 (1988-1996) interior temp sensor Wiring diagram

BATTERY BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/WHT WIRE BLOWER MOTOR BLOWER POTENTIOMETER BLOWER RELAY (IN POWER DISTRIBUTION BOX) BLOWER RESISTORS BLOWER SWITCH BLU WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE CONTROL PANEL ENGINE CONTROL MODULE (DME) (IN E-BOX) 1995 VFTC FRONT POWER DISTRIBUTION BOX FUSE 19 FUSE 27 GRN WIRE GRN/BLU/YEL WIRE GRN/BRN WIRE GRN/BRN/YEL WIRE GRN/GRY WIRE GRN/RED WIRE HI ME HOT AT ALL TIMES IGNITION SWITCH INTERIOR TEMP SENSOR LEFT ROTARY TEMP SWITCH RIGHT ROTARY TEMP SWITCH MAX NCA WIRE OFF ORG/ WIRE POWER DISTRIBUTION RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RUN WIRE SENSOR FAN THERMAL LIMITER VIO/GRY WIRE W/ PARK VENTILATION W/O PARK VENTILATION WATER VALVE SWITCH YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
