BMW 5 series GT F07 (2009-2013) Base radio circuit, basic

AERIAL DIVERSITY ALL ROUND VISION CAMERA AUX-IN CONNECTION (W/O HIGH INTERFACE BOX) BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BRN WIRE BRN/YEL WIRE BUTION SYSTEM CENTRAL GATEWAY MODULE COMPUTER DATA LINES SYSTEM DVD CHANGER (LEFT SIDE OF REAR COMPT) ELECTRONIC VIDEO SWITCH NIGHT VISION MODULE FUSE 119 FUSE 120 GLOVE COMPARTMENT USB CONNECTION GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT HOT W/ TERMINAL INTERIOR MOST DATA LIGHTS BUS CIRCUIT SYSTEM MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE ORG/GRN WIRE POWER DISTRI- POWER DISTRIBUTION REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) FUSE 118 REAR SEAT ENTERTAINMENT REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE ROOF AERIAL SYSTEM W/O VIDEO SWITCH, W/ ALL ROUND VISION CAMERA W/O VIDEO SWITCH, W/ W/ NIGHT VIDEO VISION SWITCH CAMERA WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE

BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BRN WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM FUSE 58 GRN WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT HOT AT ALL TIMES JUNCTION BOX (RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT WOOFER LEFT REAR MID RANGE SPEAKER (GT) LEFT REAR MID RANGE SPEAKER 2 (EXCEPT GT) MICROPHONE (W/O TELEPHONE) (SEDAN: IN OVERHEAD CONSOLE) NCA WIRE ORG/ WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER RIGHT REAR MID- RANGE SPEAKER (GT) RIGHT REAR MID- RANGE SPEAKER 2 (EXCEPT GT) ROOF AERIAL SATELLITE TUNER WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/RED WIRE
