Lane departure warning circuit, without camera for BMW 5 series GT F07 (2009-2013)
Lane departure warning circuit, without camera
3 4 PNK WIRE
5 6 PNK WIRE
BRN WIRE
BRN/YEL WIRE
CENTRAL GATEWAY MODULE
COMPUTER DATA LINES SYSTEM
FOOTWELL MODULE
FUSE 131 HOLDER (RIGHT SIDE OF REAR COMPT)
GRN WIRE
GRN/BLU WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT W/
LANE DEPARTURE WARNING
PNK WIRE
REAR FUSE
RELAY ENERGIZED
SLAVE LANE DEPARTURE WARNING
STEERING COLUMN SWITCH CLUSTER
YEL/BRN WIRE
YEL/RED WIRE
