BMW 4 series G22/G23 (2020-2024) windshield panel unlocked hall effect sensor Wiring diagram
This page shows the only wiring diagram for the component.windshield panel unlocked hall effect sensor, which is found in the car BMW 4 series G22/G23 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield panel unlocked hall effect sensor (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BRN WIRE
COWL PANEL LOCKED HALL EFFECT SENSOR
FUSE 226
FUSE 258
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
LEFT CONVERTIBLE TOP LOCKED, CLOSED HALL EFFECT SENSOR
OPEN SOFT TOP COMPARTMENT LID HALL EFFECT SENSOR
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT CLOSED CONVERTIBLE TOP COMPARTMENT LID HALL EFFECT SENSOR
SOFT TOP DRIVE
TOP DRIVE UNIT RELAY
WINDSHIELD PANEL SENSOR SYSTEM
WINDSHIELD PANEL UNLOCKED HALL EFFECT SENSOR
YEL WIRE
Go to component -> Convertible top circuit (2 of 3) -> WINDSHIELD PANEL UNLOCKED HALL EFFECT SENSOR
