BMW 4 series G22/G23 (2020-2024) oil level sensor Wiring diagram
This page shows the only wiring diagram for the component.oil level sensor, which is found in the car BMW 4 series G22/G23 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil level sensor (1 of 1)
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRN WIRE
COOLANT EXPANSION TANK SHUTOFF VALVE
COOLANT TEMPERATURE SENSOR
CRANKSHAFT SENSOR
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
ENGINE OIL PRESSURE SENSOR
FUSE 406
HOT AT ALL TIMES
IGNITION COIL CYLINDER 1
IGNITION COIL CYLINDER 2
IGNITION COIL CYLINDER 4
KNOCK SENSOR
KNOCK SENSOR #2
LOW TEMPERATURE COOLANT CIRCUIT COOLANT PUMP
NCA WIRE
OIL LEVEL SENSOR
RED WIRE
RED/GRN WIRE
SPARK PLUG
TURBOCHARGER COOLANT PUMP
VIO WIRE
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (4 of 6) -> OIL LEVEL SENSOR
