BMW 4 series G22/G23 (2020-2024) mirror fold- in drive Wiring diagram
This page shows the only wiring diagram for the component.mirror fold- in drive, which is found in the car BMW 4 series G22/G23 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror fold- in drive (1 of 1)
ADJUSTMENT DRIVE
AUXILIARY TURN SIGNAL LAMP
BLK WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR SWITCH BLOCK
ELECTROCHROMIC MIRROR
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FUSE 67
FUSE 68
GRN WIRE
GRY WIRE
HOT W/ TERMINAL
LANE CHANGE WARNING LED
LEFT FOOTWELL)
MIRROR ELECTRONICS
MIRROR FOLD- IN DRIVE
MIRROR HEATING
RED WIRE
RED/GRN WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Memory mirrors circuit, w/o lin bus function -> MIRROR FOLD- IN DRIVE
