BMW 4 series G22/G23 (2020-2024) front passenger seat backrest near panel lighting Wiring diagram
This page shows the only wiring diagram for the component.front passenger seat backrest near panel lighting, which is found in the car BMW 4 series G22/G23 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger seat backrest near panel lighting (1 of 1)
AUXILIARY CONTROL UNIT
AUXILIARY HEATER COOLANT CHANGEOVER VALVE
AUXILIARY HEATER FUEL METERING PUMP
AUXILIARY WATER PUMP
BLK WIRE
BRN WIRE
CAN BUS TERMINAL RESISTOR 33
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CONVERTIBLE TOP COMPARTMENT FLOOR SWITCH 2
CONVERTIBLE TOP MODULE
COUPE
COUPE, GRAN COUPE
ELECTRICAL EXHAUST FLAP
ELECTRICAL EXHAUST FLAP 2
FRONT PASSENGER SEAT BACKREST NEAR PANEL LIGHTING
FRONT PASSENGER SEAT BELT EXTENDER
FRONT PASSENGER SEAT BELT EXTENDER CONTROLLER
HYBRID PRESSURE REFUELING ELECTRONIC CONTROL UNIT
INDEPENDENT AUXILIARY HEATER
INTERFERENCE SUPPRESSION FILTER
LEFT HEADLIGHT
LEFT REAR NEAR RANGE RADAR SENSOR
NATURAL VACUUM LEAK DETECTION
NCA WIRE
REAR PASSENGER'S SIDE FOOTWELL LIGHT
REAR POWER DISTRIBUTION BOX
REAR VIEW CAMERA SHIELD
RIGHT BACKREST REMOTE UNLOCKING ELECTRIC MOTOR
RIGHT REAR MICROWAVE SENSOR
RIGHT REAR NEAR RANGE RADAR SENSOR
RIGHT REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
TELEMATIC COMMUNICATION BOX
WHT WIRE
Go to component -> Ground distribution circuit (6 of 7) -> FRONT PASSENGER SEAT BACKREST NEAR PANEL LIGHTING
