BMW 4 series G22/G23 (2020-2024) evaluation electronics contact free tailgate opening Wiring diagram
This page shows the only wiring diagram for the component.evaluation electronics contact free tailgate opening, which is found in the car BMW 4 series G22/G23 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram evaluation electronics contact free tailgate opening (1 of 1)
ACTIVE SOUND DESIGN
BLU WIRE
BOOSTER
CONTROLLER (IDRIVE)
ELECTROCHROMIC INTERIOR MIRROR
EVALUATION ELECTRONICS CONTACT FREE TAILGATE OPENING
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLK WIRE
HEAD UNIT
LEFT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
NCA WIRE
RECEIVER AUDIO MODULE (LEFT SIDE OF LUGGAGE COMPT)
RED WIRE
RED/YEL WIRE
RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
SIREN, TILT SENSOR
W/ CAR SHARING MODULE
W/ DRIVER CAMERA SYSTEM W/O DRIVER CAMERA SYSTEM
W/O CAR SHARING MODULE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> High/low bus circuit (4 of 8) -> EVALUATION ELECTRONICS CONTACT FREE TAILGATE OPENING
