BMW 4 series G22/G23 (2020-2024) driver's seat adjustment w/ valve block backrest Wiring diagram
This page shows the only wiring diagram for the component.driver's seat adjustment w/ valve block backrest, which is found in the car BMW 4 series G22/G23 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat adjustment w/ valve block backrest (1 of 1)
AUTOMATIC REAR AIR CONDITIONING OPERATING FACILITY
BLK WIRE
BRN WIRE
CONVENIENCE CHARGING ELECTRONICS
COOLANT SHUTOFF VALVE
DIAGNOSTIC SOCKET
DOOR INSIDE DOOR HANDLE LIGHT
DRIVER BACKREST TRIM LIGHTING
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER OUTSIDE DOOR HANDLE ELECTRONICS
DRIVER SEAT BELT EXTENDER CONTROLLER
DRIVER SEAT MODULE
DRIVER VALVE BLOCK FOR LUMBAR SUPPORT BACKREST W/ ADJUSTMENT
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR COURTESY LIGHTS
DRIVER'S DOOR ENTRY LIGHTING
DRIVER'S DOOR POCKET LIGHTING
DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SEAT ADJUSTMENT W/ VALVE BLOCK BACKREST
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SEAT LUMBAR SUPPORT SWITCH
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE CONTROL ELECTRONICS NECK WARMER
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
ELECTRIC AUXILIARY HEATER
HOOD CONTACT SWITCH
LEFT BACKREST REMOTE UNLOCKING ELECTRIC MOTOR
LEFT FOOTWELL)
LEFT FRONT MICROWAVE SENSOR
NCA WIRE
REAR DRIVER'S SIDE FOOTWELL LIGHT
REAR DRIVER'S SIDE SEAT HEATING MODULE
REFUELING BUTTON
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
VEHICLE INTERIOR TAILGATE BUTTON
VERTICAL DYNAMICS PLATFORM
WIPER DRIVE
Go to component -> Ground distribution circuit (3 of 7) -> DRIVER'S SEAT ADJUSTMENT W/ VALVE BLOCK BACKREST
