BMW 4 series F32/F33 facelift (2017-2020) water injection valve block Wiring diagram
This page shows the only wiring diagram for the component.water injection valve block, which is found in the car BMW 4 series F32/F33 facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram water injection valve block (1 of 1)
A/C COMPRESSOR
BOOT LID/ TAILGATE LOCK
BRN WIRE
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
COUPE
COUPE CONVERTIBLE
COUPE, GRAN COUPE
DC/DC CONVERTER
DIGITAL MOTOR ELECTRONICS
ELECTRICAL EXHAUST FLAP
ELECTRICAL EXHAUST FLAP 2
ELECTRONIC DAMPER CONTROL
ELECTRONIC TRANSMISSION CONTROL
FRONT PASSENGER SEAT BELT EXTENDER CONTROLLER
GRAN COUPE
LEFT OUTER TAILLIGHT
LOADING AID SWITCH
NATURAL VACUUM LEAK DETECTION TEMPERATURE SENSOR, PRESSURE SWITCH
NCA WIRE
PASSENGER'S SIDE REAR COURTESY LIGHTING
PASSENGER'S SIDE REAR POWER WINDOW SWITCH
REAR ELECTRONIC MODULE
REAR FUSE CARRIER
REAR INTERIOR LIGHT
REAR PASSENGER'S SIDE DOOR LOCK
REAR PASSENGER'S SIDE DOOR PANEL LIGHTING
REAR PASSENGER'S SIDE DOOR SEAT SWITCH CLUSTER
REAR PASSENGER'S SIDE ENTRY LIGHT
REGULATED REAR AXLE DIFFERENTIAL LOCK
RIGHT "B" PILLAR LIGHTING
RIGHT OUTER TAILLIGHT
RIGHT REAR SIDE TRIM PANEL LIGHTING
SIREN W/ TILT ALARM SENSOR
SIREN W/ TILT SENSOR
TRAILER SOCKET (12-PIN)
TRAILER SOCKET (13-PIN)
TRANSFER BOX
W/ TRAILER MODULE
W/O TRAILER MODULE
WATER INJECTION VALVE BLOCK
WATER TANK LEVEL SENSOR
Go to component -> Ground distribution circuit (3 of 4) -> WATER INJECTION VALVE BLOCK
