BMW 4 series F32/F33 facelift (2017-2020) roof package set up hall effect sensor Wiring diagram
This page shows the only wiring diagram for the component.roof package set up hall effect sensor, which is found in the car BMW 4 series F32/F33 facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roof package set up hall effect sensor (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
FUSE 141
FUSE 143
FUSE 506
FUSE BOX
GRN/VIO WIRE
HARDTOP DRIVE (CENTER FRONT LUGGAGE COMPT)
HARDTOP DRIVE RELAY 1
HARDTOP DRIVE RELAY 2
HOT AT ALL TIMES
HOT W/
LEFT AUTOMATIC SOFT CLOSE DRIVE
LEFT LOADING AID CHANGEOVER ELECTRIC MOTOR
NCA WIRE
POWER DISTRIBUTION SYSTEM
REAR FUSE CARRIER
RED WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT AUTOMATIC SOFT CLOSE DRIVE
RIGHT LOADING AID CHANGEOVER ELECTRIC MOTOR
RIGHT ROOF PACKAGE STORED HALL EFFECT SENSOR
ROOF PACKAGE SET UP HALL EFFECT SENSOR
VIO/BLU WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Convertible top circuit (2 of 3) -> ROOF PACKAGE SET UP HALL EFFECT SENSOR
