BMW 4 series F32/F33 facelift (2017-2020) lane change warning slave Wiring diagram
This page shows the only wiring diagram for the component.lane change warning slave, which is found in the car BMW 4 series F32/F33 facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lane change warning slave (1 of 1)
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR MIRROR
DRIVER'S DOOR SWITCH BLOCK
FRONT ELECTRONIC MODULE
FRONT PASSENGER EXTERIOR MIRROR
FUSE 148
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT W/
LANE CHANGE WARNING
LANE CHANGE WARNING LED
LANE CHANGE WARNING SLAVE
MIRROR ELECTRONICS
PNK WIRE
POWER DISTRIBUTION SYSTEM
REAR FUSE CARRIER
RELAY ENERGIZED
STEERING COLUMN SWITCH CLUSTER
WHT/BRN WIRE
YEL WIRE
Go to component -> Lane departure warning circuit, w/o camera -> LANE CHANGE WARNING SLAVE
