BMW 4 series F32/F33 facelift (2017-2020) glove compartment light switch Wiring diagram
This page shows the only wiring diagram for the component.glove compartment light switch, which is found in the car BMW 4 series F32/F33 facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram glove compartment light switch (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP MODULE
COUPE, GRAN COUPE CONVERTIBLE W/ HIGH LIGHT PACKAGE W/ LOW LIGHT PACKAGE
FRONT POWER DISTRIBUTION BOX
FUSE 28
FUSE 53
FUSE 57
GLOVE COMPARTMENT LIGHT
GLOVE COMPARTMENT LIGHT SWITCH
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR
INTERIOR LIGHT)
INTERIOR LIGHTING
LEFT FRONT VANITY MIRROR LIGHT
LEFT FRONT VANITY MIRROR SWITCH
LEFT READING
LIGHT
LIGHT LOCATOR
LIGHTING
LIGHTING BUTTON
POWER DISTRIBUTION SYSTEM
READING
READING LIGHT
REAR INTERIOR LIGHT
REAR INTERIOR LIGHT (COUPE, GRAN COUPE)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT VANITY MIRROR LIGHT
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT READING
RIGHT READING LIGHT LOCATOR LIGHTING BUTTON
ROOF FUNCTION CENTER (W/ HIGH LIGHT PACKAGE)
ROOF FUNCTION CENTER (W/ LOW LIGHT PACKAGE)
ROOF FUNCTION CENTER (W/O INTERIOR LIGHT PACKAGE)
W/O INTERIOR LIGHT PACKAGE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> GLOVE COMPARTMENT LIGHT SWITCH
