BMW 4 series F32/F33 facelift (2017-2020) front passenger's exterior mirror Wiring diagram
This page shows the only wiring diagram for the component.front passenger's exterior mirror, which is found in the car BMW 4 series F32/F33 facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's exterior mirror (1 of 1)
ALL ROUND VISION CAMERA
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE CONTROL PANEL
COMPUTER DATA LINES SYSTEM
DRIVER'S EXTERIOR MIRROR
EXTERIOR MIRROR CAMERA
FRONT PASSENGER'S EXTERIOR MIRROR
FUSE 154
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEAD UNIT
HOT W/ TERMINAL
INTEGRATED CHASSIS MANAGEMENT
LEFT BUMPER CAMERA
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
REAR FUSE CARRIER
RED WIRE
REVERSING CAMERA
RIGHT BUMPER CAMERA
W/ CIC
W/O CIC
WHT WIRE
YEL/BLU WIRE
Go to component -> All around vision camera circuit -> FRONT PASSENGER'S EXTERIOR MIRROR
