BMW 4 series F32/F33 facelift (2017-2020) boot lid contact sig Wiring diagrams
This page contains all the electrical diagrams for the component. boot lid contact sig, in which he is found in the car BMW 4 series F32/F33 facelift (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram boot lid contact sig (1 of 2)
BLK WIRE
BLU/GRY WIRE
BOOT LID CONTACT SIG
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
BUS SIG
CENTRAL LOCKING BUTTON HAZARD WARNING SWITCH OPERATING UNIT
CENTRAL LOCKING DRIVE ACT
COMPUTER DATA LINES SYSTEM
COUPE
EXTERIOR BOOT LID BUTTON
EXTERIOR BOOT LID BUTTON SIG
FUSE 500
FUSE BOX
GRY/BRN WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOTEL POSITION SWITCH
LEFT LUGGAGE COMPARTMENT LOCK
LID BUTTON
LID CONTACT
LOCK DRV
REAR ELECTRONIC MODULE
REAR OF LUGGAGE COMPT)
RED WIRE
RED/GRY WIRE
RIGHT LUGGAGE COMPARTMENT LOCK
TAILGATE CENTRAL LOCKING DRIVE ENGINE
TERM 30 SPLY
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Anti-theft & central locking circuit (3 of 3) -> BOOT LID CONTACT SIG
