Contact-free tailgate opening circuit for BMW 4 series Gran Coupe F36 (2013-2017)
Contact-free tailgate opening circuit
BLK WIRE
BLU/YEL WIRE
BRN WIRE
BUMPER AERIAL
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CONTACT-FREE TAILGATE OPENING LOWER SENSOR
CONTACT-FREE TAILGATE OPENING UPPER SENSOR
FRONT ELECTRONIC MODULE
FUSE 150
GRY/BLK WIRE
GRY/RED WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
REAR FUSE CARRIER
RED/GRY WIRE
