BMW 3 series G20/G21 facelift (2022-2024) w/o surround view camera Wiring diagram
This page shows the only wiring diagram for the component.w/o surround view camera, which is found in the car BMW 3 series G20/G21 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o surround view camera (1 of 1)
ALL ROUND VISION CAMERA
BLU WIRE
CAMERA BASED DRIVER SUPPORT SYSTEMS
CENTER STACK LIGHTING
DASHBOARD LIGHTING
DASHBOARD LIGHTING 2
DASHBOARD LIGHTING 3
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT LUMBAR SUPPORT SWITCH
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FROM FUSE 55 (DIAGRAM 3 OF 8)
FRONT CENTER ARMREST LIGHT
FRONT INTERIOR LIGHT
FRONT PASSENGER LUMBAR SUPPORT SWITCH
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT SWITCH
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FUSE 60
FUSE 61
FUSE 62
FUSE 64
FUSE 65
FUSE 66
FUSE 71
FUSE 73
FUSE 76
GLOVE BOX LIGHT SWITCH
GRN WIRE
INSTRUMENT PANEL
LEFT FRONT FOOTWELL LIGHT
LEFT FRONT VANITY MIRROR LIGHT
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
REAR DRIVER'S SIDE DOOR POCKET LIGHTING
REAR DRIVER'S SIDE DOOR POCKET LIGHTING 2
REAR DRIVER'S SIDE FOOTWELL LIGHT
REAR DRIVER'S SIDE INSIDE DOOR HANDLE LIGHT
REAR INTERIOR LIGHT
REAR PASSENGER'S SIDE FOOTWELL LIGHT
REAR VIEW CAMERA
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT VANITY MIRROR LIGHT
TO FUSE 67 (DIAGRAM 5 OF 8)
TOP REAR DRIVER'S SIDE DOOR TRIM PANEL LIGHTING
W/O SURROUND VIEW CAMERA
Go to component -> Power distribution circuit (4 of 8) -> W/O SURROUND VIEW CAMERA
