BMW 3 series G20/G21 facelift (2022-2024) telematics antenna Wiring diagrams
This page contains all the electrical diagrams for the component. telematics antenna, in which he is found in the car BMW 3 series G20/G21 facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram telematics antenna (1 of 8)
Go to component -> Base radio circuit, w/ active sound design (5 of 6) -> TELEMATICS ANTENNA
Wiring diagram telematics antenna (2 of 8)
Go to component -> Base radio circuit, w/o active sound design (2 of 4) -> TELEMATICS ANTENNA
Wiring diagram telematics antenna (3 of 8)
Go to component -> Hifi radio circuit, w/ active sound design (5 of 6) -> TELEMATICS ANTENNA
Wiring diagram telematics antenna (4 of 8)
Go to component -> Hifi radio circuit, w/o active sound design (4 of 5) -> TELEMATICS ANTENNA
Wiring diagram telematics antenna (5 of 8)
Go to component -> Navigation circuit, w/ hifi radio & active sound design (5 of 6) -> TELEMATICS ANTENNA
Wiring diagram telematics antenna (6 of 8)
Go to component -> Navigation circuit, w/ hifi radio w/o active sound design (4 of 5) -> TELEMATICS ANTENNA
Wiring diagram telematics antenna (7 of 8)
Go to component -> Navigation circuit, w/o hifi radio & active sound design (2 of 4) -> TELEMATICS ANTENNA
Wiring diagram telematics antenna (8 of 8)
Go to component -> Navigation circuit, w/o hifi radio w/ active sound design (5 of 6) -> TELEMATICS ANTENNA
