BMW 3 series G20/G21 facelift (2022-2024) left rear vertical acceleration sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear vertical acceleration sensor, which is found in the car BMW 3 series G20/G21 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear vertical acceleration sensor (1 of 1)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSE 29
FUSE 39
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/WHT (OR GRY/BRN) WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT FRONT RIDE HEIGHT SENSOR
LEFT FRONT VALVE COIL
LEFT FRONT VERTICAL-ACCELERATION SENSOR
LEFT REAR RIDE HEIGHT SENSOR
LEFT REAR VALVE COIL
LEFT REAR VERTICAL ACCELERATION SENSOR
ORG/ WIRE
ORG/GRN WIRE
PNK/BLK WIRE
PNK/BLU WIRE
REBOUND STAGE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT VALVE COIL
RIGHT FRONT VERTICAL-ACCELERATION SENSOR
RIGHT REAR VALVE COIL
RIGHT REAR VERTICAL ACCELERATION SENSOR
VERTICAL DYNAMICS PLATFORM (LEFT KICK PANEL)
VIO WIRE
VIO/BLU WIRE
W/ VERTICAL DYNAMICS PLATFORM
W/O VERTICAL DYNAMICS PLATFORM
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Electronic suspension circuit -> LEFT REAR VERTICAL ACCELERATION SENSOR
