BMW 3 series G20/G21 facelift (2022-2024) left multi-function steering column switch cluster Wiring diagram
This page shows the only wiring diagram for the component.left multi-function steering column switch cluster, which is found in the car BMW 3 series G20/G21 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left multi-function steering column switch cluster (1 of 1)
ACCELERATOR PEDAL MODULE
BLK/BLU WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BODY DOMAIN CONTROLLER
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
CENTER CONSOLE CONTROL
CLUTCH MODULE (M/T)
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS
ELECTROMOTIVE THROTTLE ACTUATOR
FUSE 14
FUSE 208
FUSE 70
GEAR SELECTOR SWITCH
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GROUND DISTRIBUTION SYSTEM
HOT W/
HOT W/ VALVETRONIC RELAY ENERGIZED
INTEGRATED SUPPLY MODULE
LEFT MULTI-FUNCTION STEERING COLUMN SWITCH CLUSTER
LONG- DISTANCE RANGE FRONT RADAR SENSOR HEATING
LONG-DISTANCE RANGE FRONT RADAR SENSOR
NCA WIRE
OPTIONAL EQUIPMENT SYSTEM
REAR POWER DISTRIBUTION BOX
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH CLUSTER
STEERING COLUMN SWITCH CLUSTER
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Cruise control circuit -> LEFT MULTI-FUNCTION STEERING COLUMN SWITCH CLUSTER
