BMW 3 series G20/G21 facelift (2022-2024) front right ventilation grille Wiring diagram
This page shows the only wiring diagram for the component.front right ventilation grille, which is found in the car BMW 3 series G20/G21 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front right ventilation grille (1 of 1)
ALL ROUND VISION CAMERA
AUTOMATIC AIR RECIRCULATION CONTROL SENSOR
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CAMERA BASED DRIVER SUPPORT SYSTEMS
CAN BUS TERMINAL RESISTOR 11
CENTER CONSOLE CONTROL PANEL
CLUTCH MODULE
COOLANT LEVEL SENSOR
DASHBOARD LIGHTING
DASHBOARD LIGHTING 2
DASHBOARD LIGHTING 3
DIAGNOSTIC SOCKET
DISPLAY GROUP
DRIVER CAMERA SYSTEM
DRIVER'S DOOR CENTRAL LOCKING BUTTON
ELECTRICAL MACHINE ELECTRONICS
ELECTROCHROMIC INTERIOR MIRROR
ETHERNET SWITCH
FRONT CENTER ARMREST LIGHT
FRONT RIGHT VENTILATION GRILLE
LEFT FRONT FOOTWELL LIGHT
LEFT FRONT VANITY MIRROR SWITCH
LEFT ILLUMINATED CARPET
LEFT REAR DOOR SILL LIGHT STRIP
NCA WIRE
OPTIONAL EQUIPMENT SYSTEM
PASSENGER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
RAIN/LIGHT/ SOLAR CONDENSATION SENSOR
REAR INTERIOR LIGHT
REAR PASSENGER SIDE SILL COURTESY LIGHT
REAR PASSENGER'S SIDE COURTESY LIGHT
REAR PASSENGER'S SIDE DOOR POCKET LIGHTING
REAR PASSENGER'S SIDE INSIDE DOOR HANDLE LIGHT
REAR PASSENGER'S SIDE OUTSIDE DOOR HANDLE ELECTRONICS
REMOTE CONTROL RECEIVER
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT ILLUMINATED CARPET
ROOF FUNCTION CENTER
TOP REAR PASSENGER DOOR TRIM PANEL LIGHTING
W/O INTERIOR LIGHT PACKAGE
Go to component -> Ground distribution circuit (6 of 7) -> FRONT RIGHT VENTILATION GRILLE
