BMW 3 series G20/G21 facelift (2022-2024) emergency crews separation point Wiring diagram
This page shows the only wiring diagram for the component.emergency crews separation point, which is found in the car BMW 3 series G20/G21 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram emergency crews separation point (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN (OR BLK) WIRE
BRN WIRE
ELECTRIC VACUUM PUMP
ELECTRICAL MACHINE TEMPERATURE SENSOR
EMERGENCY CREWS SEPARATION POINT
FUSE 602
FUSE HOLDER
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HIGH VOLTAGE SAFETY CONNECTOR
HOT AT ALL TIMES
LEFT "C" PILLAR)
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT REFRIGERANT SHUTOFF VALVE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
ROTOR POSITION SENSOR
STARTER UNIT SAFETY BATTERY TERMINAL GAS GENERATOR
TOP OF TRANSMISSION)
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo hybrid (10 of 14) -> EMERGENCY CREWS SEPARATION POINT
