BMW 3 series G20/G21 facelift (2022-2024) electric auxiliary heater coolant changeover valve Wiring diagram
This page shows the only wiring diagram for the component.electric auxiliary heater coolant changeover valve, which is found in the car BMW 3 series G20/G21 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electric auxiliary heater coolant changeover valve (1 of 1)
ACTIVE SOUND DESIGN
AUXILIARY HEATER COOLANT CHANGEOVER VALVE
AUXILIARY HEATER FUEL METERING PUMP
AUXILIARY WATER PUMP
BLK WIRE
BOOSTER
BRN WIRE
CAR SHARING MODULE
CD DRIVE
COUPE
ELECTRIC AUXILIARY HEATER COOLANT CHANGEOVER VALVE
ELECTRIC VACUUM PUMP
EXCEPT 3.0L TURBO
FANFARE HORN BUTTON
HEAD UNIT
HEAD UNIT BASIC
HEAD UNIT HIGH, MID
HIFI AMPLIFIER
IGNITION COIL CYLINDER 1
IGNITION COIL CYLINDER 2
IGNITION COIL CYLINDER 3
IGNITION COIL CYLINDER 4
INDEPENDENT AUXILIARY HEATER
LEFT HEADLIGHT
LEFT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
LEFT SHIFT PADDLE
LEFT-HAND MULTI-FUNCTION STEERING COLUMN SWITCH CLUSTER
NCA WIRE
PREPARING THE NFC READER
REAR WINDOW DEFOGGER
RECEIVER AUDIO MODULE
RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
RIGHT SHIFT PADDLE
STEERING COLUMN SWITCH CLUSTER
TELEMATIC COMMUNICATION BOX SHIELD
USB CHARGING SOCKET 2
USB CHARGING SOCKET 3
USB- HUB
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
Go to component -> Ground distribution circuit (2 of 7) -> ELECTRIC AUXILIARY HEATER COOLANT CHANGEOVER VALVE
