BMW 3 series G20/G21 facelift (2022-2024) driver's seat backrest heating Wiring diagrams

AIR CONDITIONING BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT MODULE DRIVER THIGH SUPPORT HEATING DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT SURFACE HEATING FRONT PASSENGER SEAT MODULE FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS FRONT PASSENGER SEAT OCCUPANCY DETECTION SEAT CUSHION HEATER/SENSOR FRONT PASSENGER THIGH SUPPORT HEATING FRONT PASSENGER'S SEAT BACKREST HEATING FUSE 55 FUSE 56 GRN WIRE GRN/VIO WIRE GRY WIRE NCA WIRE RED WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX VIO WIRE W/ EXTENDABLE THIGH SUPPORT W/O EXTENDABLE THIGH SUPPORT WHT WIRE YEL WIRE

AIR CONDITIONING BLK WIRE BLU WIRE BLU/RED WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER THIGH SUPPORT HEATING DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT HEATING ELECTRONICS DRIVER'S SEAT SURFACE HEATING FRONT PASSENGER SEAT HEATING ELECTRONICS FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS FRONT PASSENGER SEAT OCCUPANCY DETECTION SEAT CUSHION HEATER/SENSOR FRONT PASSENGER THIGH SUPPORT HEATING FRONT PASSENGER'S SEAT BACKREST HEATING FUSE 48 FUSE 52 GRN WIRE GRN/VIO WIRE GRY WIRE NCA WIRE REAR DRIVER'S SIDE SEAT HEATING MODULE REAR PASSENGER'S SIDE SEAT HEATING MODULE RED WIRE RED/GRN WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX VIO WIRE W/ EXTENDABLE THIGH SUPPORT W/O EXTENDABLE THIGH SUPPORT WHT WIRE YEL WIRE
