BMW 3 series G20/G21 (2018-2023) rear passenger inside door handle light Wiring diagram
This page shows the only wiring diagram for the component.rear passenger inside door handle light, which is found in the car BMW 3 series G20/G21 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear passenger inside door handle light (1 of 1)
BLU WIRE
DRIVER OUTSIDE DOOR HANDLE ELECTRONICS
DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
FRONT CENTER VENTILATION GRILLE
FRONT INTERIOR LIGHT
FRONT PASSENGER INSIDE DOOR HANDLE LIGHT
FRONT PASSENGER'S DOOR POCKET LIGHTING
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRY WIRE
LIGHT OPERATING UNIT
PNK/BLU WIRE
RAIN/LIGHT/ SOLAR CONDENSATION SENSOR
REAR INTERIOR LIGHT
REAR PASSENGER INSIDE DOOR HANDLE LIGHT
REAR PASSENGER'S SIDE DOOR POCKET LIGHTING
REAR PASSENGER'S SIDE FOOTWELL LIGHT
RED WIRE
TOP FRONT PASSENGER DOOR TRIM PANEL LIGHTING
TOP REAR PASSENGER DOOR TRIM PANEL LIGHTING
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Computer data lines circuit (7 of 8) -> REAR PASSENGER INSIDE DOOR HANDLE LIGHT
