BMW 3 series G20/G21 (2018-2023) rear center console interior antenna wiring diagram
This page shows the only wiring diagram for the component.rear center console interior antenna, which is found in the car BMW 3 series G20/G21 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear center console interior antenna wiring diagram (1 of 1)
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FRONT CENTER CONSOLE INTERIOR ANTENNA
FUSE 244
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
HOT AT ALL TIMES
LEFT "C" PILLAR)
LEFT EXTERIOR ANTENNA
PASSENGER OUTSIDE DOOR HANDLE ELECTRONICS
REAR CENTER CONSOLE INTERIOR ANTENNA
REAR DRIVER SIDE OUTSIDE DOOR HANDLE ELECTRONICS
REAR PASSENGER SIDE OUTSIDE DOOR HANDLE ELECTRONICS
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/WHT WIRE
REMOTE CONTROL RECEIVER
RIGHT EXTERIOR ANTENNA
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Access/start circuit (2 of 2) -> REAR CENTER CONSOLE INTERIOR ANTENNA
