BMW 3 series G20/G21 (2018-2023) left rear valve coil Wiring diagram
This page shows the only wiring diagram for the component.left rear valve coil, which is found in the car BMW 3 series G20/G21 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear valve coil (1 of 1)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSE 29
FUSE 39
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT FRONT RIDE HEIGHT SENSOR
LEFT FRONT VALVE COIL
LEFT FRONT VERTICAL-ACCELERATION SENSOR
LEFT REAR RIDE HEIGHT SENSOR
LEFT REAR VALVE COIL
ORG/ WIRE
ORG/GRN WIRE
PNK/BLK WIRE
PNK/BLU WIRE
REBOUND STAGE
REBOUND STAGE RIGHT REAR VALVE COIL
RED WIRE
RED/GRN WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT VALVE COIL
RIGHT FRONT VERTICAL-ACCELERATION SENSOR
VERTICAL DYNAMICS PLATFORM (LEFT KICK PANEL)
VIO WIRE
VIO/BLU WIRE
W/ VERTICAL DYNAMICS PLATFORM
W/O VERTICAL DYNAMICS PLATFORM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Dynamic drive suspension circuit -> LEFT REAR VALVE COIL
