BMW 3 series G20/G21 (2018-2023) fully automatic trailer tow hitch electric motor Wiring diagram
This page shows the only wiring diagram for the component.fully automatic trailer tow hitch electric motor, which is found in the car BMW 3 series G20/G21 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fully automatic trailer tow hitch electric motor (1 of 1)
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
FULLY AUTOMATIC TRAILER TOW HITCH BUTTON
FULLY AUTOMATIC TRAILER TOW HITCH ELECTRIC MOTOR
FUSE 296
HOT W/ TERMINAL
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/YEL WIRE
TRAILER MODULE
TRAILER SOCKET SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Active bodyworks circuit -> FULLY AUTOMATIC TRAILER TOW HITCH ELECTRIC MOTOR
