BMW 3 series G20/G21 (2018-2023) convenience charging electronics Wiring diagram
This page shows the only wiring diagram for the component.convenience charging electronics, which is found in the car BMW 3 series G20/G21 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convenience charging electronics (1 of 1)
AUTOMATIC REAR AIR CONDITIONING OPERATING FACILITY
AUXILIARY HEATER ELECTRIC
BRN WIRE
CONVENIENCE CHARGING ELECTRONICS
DIAGNOSTIC SOCKET
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER LUMBER SUPPORT/BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER OUTSIDE DOOR HANDLE ELECTRONICS
DRIVER SEAT MODULE
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR ENTRY LIGHTING
DRIVER'S DOOR GROUND LIGHTS
DRIVER'S DOOR INSIDE DOOR HANDLE LIGHT
DRIVER'S DOOR POCKET LIGHTING
DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SEAT LUMBAR SUPPORT SWITCH
DRIVER'S SEAT PNEUMATIC PUMP
HOOD CONTACT SWITCH
LEFT BACKREST REMOTE UNLOCKING ELECTRIC MOTOR
NCA WIRE
REAR DRIVER'S SIDE FOOTWELL LIGHT
REAR DRIVER'S SIDE SEAT HEATING MODULE
REFUELING BUTTON
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
TRAILER BRAKE SYSTEM PLUG CONNECTION
VEHICLE INTERIOR TAILGATE BUTTON
VERTICAL DYNAMICS PLATFORM
WIPER DRIVE
Go to component -> Ground distribution circuit (3 of 7) -> CONVENIENCE CHARGING ELECTRONICS
