BMW 3 series G20/G21 (2018-2023) charging controller for auxiliary battery Wiring diagrams
This page contains all the electrical diagrams for the component. charging controller for auxiliary battery, in which he is found in the car BMW 3 series G20/G21 (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram charging controller for auxiliary battery (1 of 2)
BLU WIRE
BOTTOM RADIATOR BLIND DRIVE
CHARGING CONTROLLER FOR AUXILIARY BATTERY
COOLANT PUMP IN LOW- TEMPERATURE COOLANT CIRCUIT 48 V
DASHBOARD LIGHTING
DASHBOARD LIGHTING 2
DASHBOARD LIGHTING 3
DRIVER'S DOOR INSIDE DOOR HANDLE LIGHT
DRIVER'S DOOR POCKET LIGHTING
ELECTRIC FAN
FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
GRN WIRE
GRN/BLU WIRE
GRY WIRE
INTELLIGENT BATTERY SENSOR
LEFT FRONT FOOTWELL LIGHT
NCA WIRE
PASSENGER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
PNK/BLU WIRE
REAR DRIVER'S SIDE DOOR INSIDE DOOR HANDLE LIGHT
REAR DRIVER'S SIDE DOOR POCKET LIGHTING
RED WIRE
RIGHT FRONT FOOTWELL LIGHT
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
TOP RADIATOR BLIND DRIVE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Computer data lines circuit (6 of 8) -> CHARGING CONTROLLER FOR AUXILIARY BATTERY
Wiring diagram charging controller for auxiliary battery (2 of 2)
12 V POWER SOCKET 2
ANTI SLIP RAILS CONTROL ELECTRONICS
BRN WIRE
CHARGING CONTROLLER FOR AUXILIARY BATTERY
DYNAMIC STABILITY CONTROL (DSC)
HKFM
LEFT INNER TAILLIGHT
LEFT LICENSE PLATE LAMP
LEFT OUTER TAILLIGHT
OUTER TAILGATE BUTTON
PARKING MANEUVERING ASSISTANT
REAR PASSENGER'S SIDE SEAT HEATING MODULE
REAR WINDOW LOCK
RIGHT INNER TAILLIGHT
RIGHT LICENSE PLATE LAMP
RIGHT OUTER TAILLIGHT
SIREN W/ TILT ALARM SENSOR
TAILGATE LOCK
TRAILER MODULE
TRAILER SOCKET
Go to component -> Ground distribution circuit (1 of 7) -> CHARGING CONTROLLER FOR AUXILIARY BATTERY
