BMW 3 series G20/G21 (2018-2023) capacitor box Wiring diagrams
This page contains all the electrical diagrams for the component. capacitor box, in which he is found in the car BMW 3 series G20/G21 (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram capacitor box (1 of 2)
ALTERNATOR
AUXILIARY BATTERY
BATTERY
BATTERY ELECTRONICS
BLK WIRE
BLU/YEL WIRE
BRN WIRE
CAPACITOR BOX
COMPUTER DATA LINES SYSTEM
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 244
FUSE 63
GRY WIRE
HOT AT ALL TIMES
HOT W/
INTELLIGENT BATTERY SENSOR
JUMP START TERMINAL
NCA WIRE
ON BATTERY)
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
SAFETY BATTERY TERMINAL GAS GENERATOR
STARTER MOTOR
TRANSFER TERMINAL POINT
VIO WIRE
YEL WIRE
Go to component -> Charging circuit -> CAPACITOR BOX
Wiring diagram capacitor box (2 of 2)
ALTERNATOR
AUXILIARY BATTERY (RIGHT SIDE OF ENGINE COMPT)
BATTERY
BATTERY ELECTRONICS
BLK WIRE
BLU/YEL WIRE
BRN (OR BLK) WIRE
BRN WIRE
CAPACITOR BOX
COMPUTER DATA LINES SYSTEM
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS
DME MAIN RELAY
DYNAMIC STABILITY CONTROL (DSC)
ELECTRIC FAN CUT-OFF RELAY
ELECTROMECHANICAL POWER STEERING
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FROM REAR POWER DISTRIBUTION BOX (DIAGRAM 5 OF 8)
FROM RIGHT FRONT POWER DISTRIBUTION BOX (DIAGRAM 3 OF 8)
FROM SAFETY BATTERY TERMINAL GAS GENERATOR (DIAGRAM 1 OF 8)
FRONT ELECTRIC AUXILIARY HEATER
FUSE 400
FUSE 401
FUSE 402
FUSE 404
FUSE 406
GRY WIRE
IGNITION, FUEL INJECTION RELAY
INTEGRATED SUPPLY MODULE (LEFT SIDE OF ENGINE COMPT)
INTELLIGENT BATTERY SENSOR
JUMP START TERMINAL
NCA WIRE
ON BATTERY)
POWER SUPPLY SENSORS/ ACTUATORS RELAY
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
SAFETY BATTERY TERMINAL GAS GENERATOR
STARTER MOTOR
TO AUXILIARY BATTERY (DIAGRAM 1 OF 8)
TO FUSE BOX (DIAGRAM 2 OF 8)
TRANSFER TERMINAL POINT
VALVETRONIC RELAY
VIO WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 8) -> CAPACITOR BOX
