Contact-free tailgate opening circuit for BMW 3 series F30/F31 facelift (2015-2020)
Contact-free tailgate opening circuit
BLK WIRE
BLU/YEL WIRE
BRN WIRE
BUMPER AERIAL
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CONTACT-FREE TAILGATE OPENING LOWER SENSOR
CONTACT-FREE TAILGATE OPENING UPPER SENSOR
FRONT ELECTRONIC MODULE
FUSE 150
GRY/BLK WIRE
GRY/RED WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
POWER DISTRIBUTION SYSTEM
REAR FUSE HOLDER
RED/GRY WIRE
RIGHT END OF DASH)
