Headlights circuit, w/ xenon lamps for BMW 3 series F30/F31 facelift (2015-2020)

BI-XENON BI-XENON SHUTTER BLK/YEL WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DAYTIME DRIVING DRIVER MODULE POWER SUPPLY FRONT ELECTRONIC MODULE FRONT POWER DISTRIBUTION BOX FUSE 10 FUSE 28 FUSE 57 GRN/BLK WIRE GRY/VIO (OR GRY) WIRE GRY/VIO WIRE GRY/YEL WIRE HEADLIGHT BEAM HEIGHT CONTROL DRIVE UNIT HEADLIGHT DRIVER MODULE HOT AT ALL TIMES HOT W/ LEFT FOG LIGHT LEFT HEADLIGHT LIGHTS) LIN BUS SIGNAL LOW BEAM LIGHT PARKING BRAKE SWITCH PARKING BRAKE SWITCH SIGNAL RED/BLU WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT END OF DASH) RIGHT FOG LIGHT SHUTTER SIDE LIGHTS/ DAYTIME DRIVING LIGHT STEERING COLUMN SWITCH CLUSTER SWIVEL MODULE TERMINAL 30 SUPPLY W/ ADAPTIVE HEADLIGHTS W/O ADAPTIVE HEADLIGHTS WHT/RED WIRE WHT/YEL WIRE XENON LAMP BULB XENON LIGHT MODULE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

BI-XENON BLK/YEL WIRE BRN WIRE BRN/BLK WIRE CENTER OF WINDSHIELD) COMPUTER DATA LINES SYSTEM DAYTIME DRIVING ELECTROCHROMIC INTERIOR REAR VIEW MIRROR GRN/BLK WIRE GRY/VIO WIRE GRY/YEL WIRE HEADLIGHT BEAM HEIGHT CONTROL DRIVE UNIT HEADLIGHT DRIVER MODULE HIGH BEAM ASSISTANT SENSOR, CONTROL LIGHT SWITCH UNIT LIGHTS) RAIN/LIGHT/SOLAR CONDENSATION SENSOR RED/WHT WIRE RIGHT HEADLIGHT SHUTTER SIDE LIGHTS/ DAYTIME DRIVING LIGHT SWIVEL MODULE W/ ADAPTIVE HEADLIGHTS W/O ADAPTIVE HEADLIGHTS WHT/YEL WIRE XENON LAMP BULB XENON LIGHT MODULE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE
